5100 Series High Power Water-cooled High Voltage VFD
The product adopts
voltage source multi-level topology, the power system adopts water-water
cooling solution, power cell with dual water circuit parallel design,
water-cooled pipe adopt quick connectors, support online plugging and
unplugging. The power c
Product Features
-
Optimized water circuit designpower cells with dual water circuits in parallel to support online plugging and unplugging.
-
Modular design of power cellThe power cell is a modular assembly design with strong expansion ability
-
High-voltage power componentsselection of high-voltage IGBT power components
-
Large capacity outputMeet the user's core load and key equipment drive control requirements
Operating Conditions
-
Ambient air temperature0℃~+40℃
-
Ambient air monthly average maximum relative humidity≤90% non-condensing (when the temperature is 25℃)
-
Altitude≤1KM
Product Parameters
| Model | RMVC/WD(5100 Water-cooled Series ) |
| Capacity Range | 10000kVA~80000kVA【10kV as example】 |
| Input Voltage | 6kV~35kV |
| Output Voltage | 6kV~13.8kV |
| System Composition | Pre-charging cabinet, phase shifting transformer, water-cooled power cell cabinet, water-cooling system cabinet, control cabinet |
| IGBT Voltage | 1700V、3300V、4500V |
| Transformer Type | Dry type phase shifting transformer; Oil type phase shifting transformer |
