Multi core water electrolysis hydrogen production device-AEM Flex 120

Flexible configuration from 70 kW to 480 kW guarantees a match with your budget and hydrogen production requirements. The modular design ensures reactivity to intermittent renewable energy, built-in redundancy and freedom to scale when you need it!

Characteristics of AEM FLEX 120 Hydrogen Production Unit

Low lead times

Receive your AEM Flex 120 and start your green hydro- gen production within just a few months. We stand for simple planning, and low lead times mean your green hydrogen pilot comes first.
Streamlined integration

Our container-free, skid-mounted electrolyser rapidly and seamlessly integrates into your existing energy pro- jects, allowing you to add hydrogen production capabili- ties without extensive site or system modifications.
Tailored production

Choose the number of AEM Stack strings to get the exact amount of hydrogen production you need – between 70 kW and 480 kW. If you start small, you will have the possibility to later add electrolyser production capacity.

Condition

8:1

Adjustment rate
12% –100%

Operational flexibility
5 – 55 °C

H₂ outlet temperature

Specifications

H₂ nominal flow	25 Nm³/h （53.9 kg/24h）
H₂ outlet pressure	Up to 35 barg (507.63 psig)
H₂ purity	Impurities: H₂O < 500 ppm, O₂ < 5 ppm
H₂ purity with optional dryer	Impurities: H₂O < 5 ppm, O₂ < 5 ppm
Nominal power consumption	Beginning of life (BOL)
Voltage	3 × 400 VAC ± 10 %
Frequency	50/60 Hz ± 10 %; THD < 5 %
H₂O nominal consumption	23 L/h (6.08 gal/h)Purified water
H₂O inlet quality	Minimum ASTM D1193-06 Type IV or recommended Type II or Type III¹
Hot startup time	0 – 100% in 100 seconds
Cold startup time	0 – 100% in 20 minutes
Dimensions	3.2 × 2.22 × 2.78 m(L × W × H)
